Alarm light on the top. Smart alarm setting: light & sound alarm, alarm range and tone can be adjusted. It also owns Sensor off alarm, monitor abnormal alarm and remark function.

Two type of printing function: American standard and National standard.

FHR2 offset printing function.

Three monitoring and display mode: Fetal, Fetal & Maternal, Maternal.

Real-time printing and timing printing.

Event remark.

Built-in high capacity rechargeable battery.

Support paper-out cache, selectable printing and auto shutdown.

Independent network communicate function, support remote, wireless, wired networking function.

It can be upgraded to maternal multi-parameter monitoring, it has various of bracket solution

G6B Standard configuration FHR, TOCO, Fetal movement

Optional configuration Twin FHR, Fishers auto fetal-analysis, fetal awake-up alarm, wireless network, wall mount, moving cart, 12 volts Power supply

G6B+ Standard configuration FHR, TOCO, Fetal movement, ECG, NIBP, SpO2, HR/PR, 2-RESP, 2-TEMP, rechargeable battery and 150mm built-in printer

Optional configuration Twin FHR, Fishers auto fetal-analysis, fetal awake-up alarm, wireless network, wall mount, moving cart, 12 volts Power supply

Specifications

FHR

Ultrasound Frequency: 1MHz±1KHz

Ultrasound input intensity: < 10mW/c㎡

Range: 30～240bpm

Accuracy: ±1bpm

Alarm limit & tolerance: Max: （30 ～ 240）bpm, tolerance: ±5%.

Min: （30 ～ 240）bpm, tolerance: ±5%

TOCO

Measurement range: 0~100%

Resolution: 1%

Pressure tolerance: +6.7%

ECG:

Lead Selection: I、II、III、aVR、aVL、aVF、V

Heart Rate Range: 15-300bpm

Accuracy: ±1bpm or ±1%, consider the larger one.

Sweep speed: 6.25 mm/s 、12.5 mm/s 、25 mm/s、50mm/s

Gain Selection: ×1/4 、×1/2、×1、×2、×4、Auto

Calibration: ±1 mv

NIBP:

Philosophy: Oscillometric method

Measurement range: Systolic　 30-270mmHg Diastolic 10-200mmHg

Mean 20-220mmHg Measurement mode: Manual/Automatic/continuous measurement

Auto-measurement cycle: 0-480mins adjustable

Other function: NIBP Trend tabulation, supplementary venipuncture function.

SPO2

Display type: Value, waveform, plethysmograph

Measurement range: 0-100%

Accuracy: 70%-100%（±2%）；50%-69%（±3%）；0%-49% （undefined）

Pulse Rate

Measurement Range: 30-250bpm

Accuracy: ±1bpm or ±2%, consider the larger one.

Respiration

Philosophy: Thoracic impedance & nasal tube

Measurement range: 0-120bpm

Accuracy: ±1bpm or ±5%, consider the larger one.

Lead Selection: RA-LA，RA-LL，LA-LL

Temperature

Number of channel: 2channerls, display T1、T2、△T

Measurement range: 25℃~45℃

Accuracy: ±0.2℃

Sensor: Standard config with skin temp sensor.

G6B Standard configuration FHR, TOCO, Fetal movement

Optional configuration Twin FHR, Fishers auto fetal-analysis, fetal awake-up alarm, wireless network, wall mount, moving cart, 12 volts Power supply

G6B+ Standard configuration FHR, TOCO, Fetal movement, ECG, NIBP, SpO2, HR/PR, 2-RESP, 2-TEMP, rechargeable battery and 150mm built-in printer

Optional configuration Twin FHR, Fishers auto fetal-analysis, fetal awake-up alarm, wireless network, wall mount, moving cart, 12 volts Power supply
